Guide COB Series – Indoor Small-Pitch LED Display | Ultra HD LED Video Wall
Guide COB Series is a high-performance indoor small-pitch LED display that combines COB (Chip On Board) and flip-chip technology to deliver ultra-high-definition visuals with exceptional durability. As our flagship small-pixel-pitch LED video wall, it is ideal for conference rooms, control centers, TV studios, and commercial digital signage.
1. Ultra-Fine Pixel Pitch for Crisp Visuals
| Specification |
Parameter |
| Pixel pitch |
P0.62
|
P0.78
|
P0.9
|
P1.2
|
| Led module size |
150*168.75mm |
150*168.75mm |
150*168.75mm |
150*168.75mm |
| Led module resolution |
242*272 dots |
192*216dots |
167*188dots |
125*141 |
| Led chip size |
3*6mil |
3*6mil |
3*6mil |
3*6mil |
| Cabinet size |
600*337.5mm |
600*337.5mm |
600*337.5mm |
600*337.5mm |
| Cabinets resolution |
960*540dots |
768*432dots |
640*360 dots |
480*270dots |
| Scan method |
1/60 scan |
1/48 scan |
1/54 scan |
1/60 scan |
| Cabinet weight |
4kg/set |
4kg/set |
4kg/set |
4kg/set |
| Brightness |
600nit |
600nit |
600nit |
600nit |
| Max power consumption |
92W/panel |
85W/panel |
75W/panel |
70W/panel |
| IP degree |
33 |
33 |
33 |
33 |
| Scan method |
1/62 scan |
1/51 scan |
1/64 scan |
1/64 scan |
| High refresh |
3840hz
|
| Frame change frequency |
50/60Hz
|
| Operating voltage |
AC110-240v (50-60Hz)
|
| Peak power consumption |
450w/m²
|
| Average power consumption |
100w/m²-300w/m²
|
| Continuous working hours |
7*24 hours
|
| Average failure-free time |
More than 10000 hours
|
| Led life |
100,000 hours
|
| Blind spot rate |
<0.0001
|
| Operating environment temperature |
Minus 10 degrees to 60 degrees
|
| Operating environment humidity |
10%-90% RH No condensation
|
- Pixel pitch options: 0.62mm – 1.2mm
- Uses micro and mini LED chips for detailed, ultra-sharp images
- Native 16:9 aspect ratio with high refresh rate of 3,840Hz
- 16-bit grayscale support ensures smooth color transitions and lifelike visuals
2. Durable & Easy-to-Maintain Design
2. Durable & Easy-to-Maintain Structure
Built for long-term indoor use, the Guide COB LED display offers exceptional durability and effortless maintenance:
- COB encapsulation technology provides superior surface strength, making the panels highly resistant to impact and wear—ideal for busy commercial or public environments.
- The fully hardwired architecture integrates the receiving card, hub board, and power supply into one efficient system, reducing failure points and simplifying installation.
- Full front-access maintenance enables quick repairs and module replacement, keeping downtime to a minimum.
- A three-in-one integrated design streamlines wiring and enhances system reliability.
- Panels support seamless splicing, allowing flexible, ultra-flat video wall configurations for any indoor application.
3. Applications of Guide COB Indoor LED Display
The Guide COB Series is suitable for various indoor LED display applications:
- Conference Rooms & Event Centers: Ideal for video conferencing, presentations, and live data visualization
- Command & Dispatch Centers: Real-time monitoring of maps, dashboards, and surveillance feeds
- TV Studios & Control Rooms: Deliver smooth, flicker-free broadcast-quality visuals
- Commercial Displays & Exhibitions: Showcase products, digital signage, and interactive content
- Video Walls & Billboards: Build high-definition indoor video walls for impactful advertising
Why Choose the Guide COB Series?
- Stunning Ultra-HD Visuals
With an impressive contrast ratio of up to 100,000:1, the Guide COB display delivers exceptional clarity, deep blacks, and vibrant colors—perfect for any high-precision indoor application.
- Energy-Saving Performance
Designed with efficiency in mind, the COB Series consumes less power while maintaining superb brightness and stability, making it an eco-friendly long-term solution.
- Engineered for Reliability
Built for continuous operation, the COB Series offers outstanding stability and long service life, ensuring consistent performance across demanding indoor environments.
- Flexible & User-Focused Design
From seamless splicing to easy integration in various spaces, the Guide COB Series provides a smooth, versatile user experience suitable for conference rooms, control centers, commercial displays, and more.
Guide COB Series sets a new standard for indoor small-pitch LED video walls, offering crisp visuals, durable panels, and flexible installation options for professional and commercial use.
